Flowpacker 300 AHM E

Small Footprint, Big Performance:

Audion Flowpacker that optimizes packaging within limited spaces

Interested in our Flowpacker 300 AHM E?

International Sales

We are more than willing to support you with your request or run a demo with your packaging

Efficient Flow Packaging                    for small-scale environments

The Audion Flowpacker AHM 300 E revolutionizes the packaging process for small-scale environments, delivering high-speed packaging of small, solid-shaped products without compromising on efficiency. With a maximum output of 90 products per minute, this compact and versatile machine is ideal for businesses seeking optimal performance in limited spaces.

Equipped with a smart sealing and folding system, integrating a rotary seal system and upper film reel, the Flowpacker 300 AHM ensures seamless operation and precise packaging. Its adjustable format conformer enhances versatility, allowing for quick adjustments to accommodate various product sizes. This Flowpacker standard features advanced functionalities such as reel end photocell and print mark detection guaranteeing reliability and efficient packaging every time.

Operators will appreciate the machine's user-friendly design, with easy access to components and a clear digital panel for seamless navigation and control.

Flowpacker 300 AHM E does not require compressed air, therefore offering reduced energy consumption and operational costs. Its compact footprint makes it the perfect solution for small production environments, while its compatibility with industry 4.0 and IoT technological platforms ensures seamless integration into modern manufacturing processes.

Experience the next level of flow packaging efficiency with the Audion Flowpacker AHM 300 E:

  • Smart Sealing & Folding system (Height adjustable cross (rotary) bar sealing system, longitudinal sealing consisting of 2 pairs of drive wheels)
  • Sophisticated features standard included (various photocells)
  • Independent control (conveyors and sealing system are independently controlled by separate motors, providing flexibility and precision in operation)
  • Compact footprint: the compact size makes AHM 300 E ideal for small production environments where space is limited.
Flowwrapper 4
Flowwrapper 2
Flowwrapper

Why Audion Flowpacker 300 AHM E suits your business:

We work together with you in providing the best quality packaging machines to help you grow your business

Richly Equipped as standard

Our fully equipped Flowpacker comes standard with advanced functionalities including a reel end photocell, print mark detection for pre-printed film, and a no-product-no-bag photocell. These features contribute to seamless operation and reliable packaging performance.  Sealing temperature, belt speeds and process statistics can easily be controlled from the user-friendly 7” full-colour touch screen display with PLC. A fully equipped solution!

Energy saving and Connecting Technology

Audion Flowpackers integrate industry 4.0 and IoT technology, ensuring seamless compatibility with contemporary manufacturing norms. With no reliance on compressed air, such as traditional flow pack machines, the AHM 300 E significantly reduces energy consumption and operational expense.

Speed combined with excellent seal quality and preciseness

The 300 AHM E can rapidly pack small, single, solid shaped products or previously grouped products with irregular shapes at high speed. The infeed conveyor, longitudinal seal system, cross seal rotary system, and outfeed conveyor are independently controlled by separate motors, providing flexibility and precision in operation. The dynamic film conformer with position indicator allows for precise adjustments.

Ergonomic packaging ensuring ultimate user comfort

Designed with optimized ergonomics, our flow packer offers operators a comfortable and efficient working environment, reducing strain and fatigue during operation. With an easy-access digital panel and components, operators can quickly navigate and maintain the machine, minimizing downtime and maximizing productivity.


300 AHM E: A fully equipped Flowpack solution

Main characteristics:

  • 300 AHM E: No air pressure required
  • Upgrade models 400 AHM E / 550 AHM E are available operating on air pressure / pneumatically driven; (specifications on request available)
  • Flow pack machine with upper film reel
  • Cross sealing system with rotary bar
  • Sliding surfaces of products in stainless steel AISI304
  • Infeed conveyor with adjustable guides and pushers which are easily adjustable/ removable for different sizes of products
  • Longitudinal sealing consisting of 2 pairs of drive wheels (manual opening and closing of the longitudinal sealing wheels)
  • Upper film reel holder with (manual closing reel holder shaft)
  • Standard dynamic film conformer with position indicator with numerical display (2 formats standard included)
  • Cross sealing bar 150 mm, manually adjustable in height (max. 60 mm)
  • Motorized product outfeed conveyor adjustable in height by handwheel
  • Easy accessible and big drawers to collect product waste
  • Photocell printmark detection sensor included
  • Photocell sensor no-product-no bag included
  • Photocell sensor end of film reel included
  • Motors configuration controlled by inverters: infeed conveyor/ cross seal bar/ longitudinal sealer/ outfeed conveyor with independent asynchronous motors
  • Motors configuration : cross sealer equipped with brushless motor
  • User-friendly 7” full-colour touch screen display with PLC:
  • Sealing temperature, belt speeds, bag length can easily be adjusted;
  • Insights in process statistics
  • Separate IN/OUT control modules for digital, analog inputs/outputs for easy connecting externa feeding systems .
  • More than 50 different product recipes can be programmed
  • Emergency stop
  • Reduced power consumption
  • Compatible with CE regulations
Flowwrapper Staand Beeld2

Videos

Benefits

The Audion Flowpacker 300 AHM E gives you the following benefits

Latest technology:
Incorporating industry 4.0 and IoT technological platforms, our machine ensures compatibility with modern manufacturing standards, enhancing efficiency and connectivity.
Versatility:
Flowpacker 300 AHM E is highly flexible and versatile, thanks to its compactness and adjustable format conformers. It can adapt to various product sizes, catering to diverse packaging needs.
Low energy cost:
AHM 300 E requires no compressed air, reducing energy consumption and operational costs
User-friendly touchscreen:
Clear 7” full-color touch screen display with PLC for intuitive control and monitoring
Ergonomics:
Designed with optimized ergonomics, our flow packer offers operators a comfortable and efficient working environment, reducing strain and fatigue during operation
Accessibility:
With an easy-access digital panel and components, operators can quickly navigate and maintain the machine, minimizing downtime and maximizing productivity.

Explore your options

Customize the Audion 300 AHM E to your needs

Easy bag opening:

Zig zag blade (a zig-zag cut above the cross seal) or Easy open blade ( a straight cut into the bag) allow for an easy bag opening.

Upgrade to fully automatic:

Handshake signal and External E-Stops are available to upgrade you flowpacker and enable the integration of robotics (infeed/outfeed) in a production line.

Variety of bag sizes

Besides the 2 format conformers that are already standard included with the 300 AHM E additional conformers are available for different bag sizes.

Extended infeed conveyor

The standard infeed conveyor of 500 mm can be extended by 100 cm (to facilitate pre-handling or regrouping of the product).

Flowwrapper 4

Everything-under-one-roof, match the 300 AHM E with Audion film

Click here
